Basic specifications
| model |
SMC 5006
|
| equipped with (connector type) |
CORE
|
| max. working pressure |
10.443 psi
|
| max. working pressure |
720 / 72 (bar/Mpa)
|
| key words |
SMC5006
|
Performance
| max. cutting force |
43.388 lbf
|
| max. cutting opening |
25 mm
|
| max. cutting opening |
1 in
|
| max. cutting force |
193 / 19.7 (kN/t)
|
General specifications
| required oil content (effective) |
10 cc
|
| required oil content (effective) |
0,3 oz
|
Dimensions, weight and temperature
| weight, ready for use |
6,5 kg
|
| weight, ready for use |
14,3 lb
|
| temperature range |
-20 + 55 °C
|
| temperature range |
-4 + 131 °F
|
| dimensions (AxBxC) |
366 x 123 x 235 mm
|
| dimensions (AxBxC) |
14.4 x 4.8 x 9.3 in
|
Safety factors / tests
| hydraulic safety factor |
2:1
|
| endurance test tool |
1000 cycles of biting in material that cannot be cut
|
| endurance test dead man’s handle |
6000 cycles
|
