Basic specifications
| model |
HDO 100
|
| max. working pressure |
10.443 psi
|
| max. working pressure |
720 / 72 (bar/Mpa)
|
| key words |
HDO100
|
Performance
| max. spreading force |
22.481 lbf
|
| stroke |
130 mm
|
| stroke |
5,1 in
|
| capacity, spreading jack |
22.481 lbf
|
| retracted length |
300 mm
|
| retracted length |
11,8 in
|
| extended length |
430 mm
|
| extended length |
16,9 in
|
| max. spreading force |
100 / 10.2 (kN/t)
|
| capacity, spreading jack |
100 / 10.2 (kN/t)
|
General specifications
| required oil content (effective) |
207 cc
|
| required oil content (effective) |
7 oz
|
| hydraulic system |
single acting
|
Dimensions, weight and temperature
| weight, ready for use |
6,7 kg
|
| weight, ready for use |
14,8 lb
|
| temperature range |
-20 + 55 °C
|
| temperature range |
-4 + 131 °F
|
| dimensions (AxBxC) |
400 x 300 x 133 mm
|
| dimensions (AxBxC) |
15.7 x 11.8 x 5.2 in
|
Safety factors / tests
| hydraulic safety ratio hose |
4:1
|
| hydraulic safety factor tool |
2:1
|
