Basic specifications
| model |
PA 04 H 2 S
|
| max. working pressure |
720 / 72 (bar/Mpa)
|
| max. working pressure |
10.443 psi
|
| equipped with (connector type) |
single hose
|
| key words |
PA04H2S
|
Performance
| capacity oil tank (effective) |
410 cc
|
| capacity oil tank (effective) |
13,9 oz
|
| capacity oil tank |
500 cc
|
| capacity oil tank |
16,9 oz
|
| number of stages |
2
|
| first stage output (per stroke) |
18,4 cc
|
| first stage output (per stroke) |
0,62 oz
|
| second stage output (per stroke) |
1,4 cc
|
| second stage output (per stroke) |
0,05 oz
|
| first stage pressure range min. |
0 psi
|
| first stage pressure range max. |
653 psi
|
| first stage pressure range |
0 – 45 / 0 – 4.5 (bar/Mpa)
|
| first stage pressure range |
0 – 653 psi
|
| second stage pressure range min. |
653 psi
|
| second stage pressure range max. |
10.443 psi
|
| second stage pressure range |
45 – 720 / 4.5 – 72 (bar/Mpa)
|
| second stage pressure range |
653 – 10443 psi
|
General specifications
| operator type |
hand
|
Dimensions, weight and temperature
| weight, ready for use |
3,5 kg
|
| weight, ready for use |
7,7 lb
|
| dimensions (AxBxC) |
485 x 135 x 165 mm
|
| dimensions (AxBxC) |
19.1 x 5.3 x 6.5 in
|
| temperature range |
-20 + 55 °C
|
| temperature range |
-4 + 131 °F
|
