Basic specifications
| model |
SR 40 PC 2
|
| equipped with (connector type) |
CORE
|
| max. working pressure |
10.443 psi
|
| max. working pressure |
720 / 72 (bar/Mpa)
|
| key words |
SR40PC2
|
Performance
| number of stages |
3
|
| first stage pressure range min. |
0 psi
|
| first stage pressure range max. |
2.176 psi
|
| first stage pressure range |
0 – 150 / 0 – 15 (bar/Mpa)
|
| first stage pressure range |
0 – 2176 psi
|
| first stage output / min. |
2.900 cc
|
| first stage output / min. |
98,1 oz
|
| second stage pressure range min. |
2.176 psi
|
| second stage pressure range max. |
4.061 psi
|
| second stage pressure range |
150 – 280 / 15 – 28 (bar/Mpa)
|
| second stage output / min. |
1.300 cc
|
| second stage output / min. |
44 oz
|
| second stage pressure range |
2176 – 4061 psi
|
| third stage pressure range min. |
4.061 psi
|
| third stage pressure range max. |
10.443 psi
|
| third stage pressure range |
280 – 720 / 28 – 72 (bar/Mpa)
|
| third stage pressure range |
4061 – 10443 psi
|
| third stage output / min. |
550 cc
|
| third stage output / min. |
18,6 oz
|
| capacity fuel tank |
3.100 cc
|
| capacity fuel tank |
104,8 oz
|
| continuous operation |
3,5 hrs
|
| sound emission (acc. to EN 13204) |
85 dB(A)
|
| sound emission (unloaded) |
84 dB(A)
|
| capacity oil tank |
6.340 cc
|
| capacity oil tank |
214,4 oz
|
| capacity oil tank (effective) |
6.000 cc
|
| capacity oil tank (effective) |
202,9 oz
|
General specifications
| operator type |
petrol engine
|
| number of tool connections |
2
|
| number of tools simultaneously usable |
2
|
| pump type |
3-stage axial pump
|
| engine |
4-stroke – 5.5 HP – 4.1 kW
|
Dimensions, weight and temperature
| weight, ready for use |
37,3 kg
|
| weight, ready for use |
82,2 lb
|
| temperature range |
-20 + 55 °C
|
| temperature range |
-4 + 131 °F
|
| dimensions (AxBxC) |
497 x 467 x 492 mm
|
| dimensions (AxBxC) |
19.6 x 18.4 x 19.4 in
|
Norms
| EN 13204 classification |
MTO
|
| NFPA 1936 compliant |
yes
|
